Plastic Water Pipe Making Machine , HDPE Pipe Extrusion Line

Plastic Water Pipe Making Machine , HDPE Pipe Extrusion Line

    • Plastic Water Pipe Making Machine , HDPE Pipe Extrusion Line
    • Plastic Water Pipe Making Machine , HDPE Pipe Extrusion Line
    • Plastic Water Pipe Making Machine , HDPE Pipe Extrusion Line
    • Plastic Water Pipe Making Machine , HDPE Pipe Extrusion Line
    • Plastic Water Pipe Making Machine , HDPE Pipe Extrusion Line
    • Plastic Water Pipe Making Machine , HDPE Pipe Extrusion Line
  • Plastic Water Pipe Making Machine , HDPE Pipe Extrusion Line

    Product Details:

    Place of Origin: Qingdao
    Brand Name: WINGS
    Certification: CE,ISO
    Model Number: SJ65

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Email negotiate
    Packaging Details: Wooden box and film
    Delivery Time: 30 workdays
    Payment Terms: T/T 30% for prepayment and 70% after machinery testing
    Supply Ability: 100 sets every year
    Contact Now
    Detailed Product Description
    Plastic Processed: PE Application: Pipe
    Screw Design: Single-screw Product Other Name: HDPE PP Pipe Machine
    Max Production Speed: 4m/min Plastic Materials: PP PE Granules
    Pipe Name: HDPE Water Or Gas Pipe Extruder Type: Single Screw Extruder
    Condition: New Inverter: ABB

    Plastic Water Pipe Making Machine , HDPE Pipe Extrusion Line


    Qingdao Wings Plastic Technology Co., LTD
    Water supply pipe line, PE HDPE water pipe line, HDPE gas pipe line, PE pipe production equipment, PE pipe production machine, PE pipe tube machine.
    With special single screw extruder, the pipe produced by a new design of shunt type compound head, which is convenient adjustment, the characteristics of discharging evenly, sizing set adopt unique slitting process and ring cooling water , to ensure the forming precision of the tube
    PE pipe production line mainly componets: single screw extruder with automatic vacuum feeding machine, extruder of marked line, copper head ,vacuum tanks, spray water tank, haul-off machine, cutting machine, stacking frame.


    PE pipe production line is mainly used for production of polyethylene (PE), high density polyethylene (HDPE) pipes, it is mainly used for water supply pipe, gas pipe, and therefore the PE pipe equipment is usually called HDPE gas pipe, water pipe production line.
    High quantity, low melting temperature.
    Special screw design, ensure high efficiency and high yield.
    Small single screw extruder used in co-extrusion marked line out
    Standard series from 10 mm - 630 mm.The spiral distribution or blue type shunt body.
    The design of the low melting temperature.The internal stress of pipe is small, internal and external surface is smooth.

    Characteristic:

    Pipe range

    16-63mm

    20-110mm

    75-160mm

    90-250mm

    110-315mm

    160-450mm

    315-630mm

    500-800mm

    Extruder

    ¢45mm

    ¢60mm

    ¢75mm

    ¢75mm

    ¢90mm

    ¢90mm

    ¢120mm

    ¢150mm

    Extruder power

    AC30kw

    DC75kw

    DC110kw

    DC110kw

    DC160kw

    DC160kw

    DC280kw

    DC335kw

    Extrusion capacity

    60-100kg

    100-150kg

    250-300kg

    250-300kg

    350-400kg

    350-400kg

    650-700kg

    850-900kg

    Max. production speed

    10m/min

    6m/min

    6m/min

    6m/min

    3 m/min

    1.2m/min

    0.9m/min

    0.7m/min





    Welcome to receive your inquiry for more information about HDPE pipe extrusion line!



    Plastic Water Pipe Making Machine , HDPE Pipe Extrusion LinePlastic Water Pipe Making Machine , HDPE Pipe Extrusion Line



    Q&A

    *Q: What’s the price of this machine please?

    *A: Dear customer, for each kind of our machines, we have lots of models.

    Generally speaking, we design the production lines according to different requirements of different machines from different customers. Therefore, the prices are different. So please kindly inform us your requirements. For example, the raw material, the output product size, capacity and etc. The more detailed, the better. Our Engineers will design a suitable production line for you.

    *Q: What is your advantage in this line?

    *A: Dear customer, we only focus on plastic pipe extrusion machinery manufacturing and development. That is much different with others, we live on pipe extrusion line, and pipe machinery customer is all for us.

    Company Profile:

    Qingdao Wings Plastic Technology Co., Ltd is located in Qingdao Jiaozhou City. Advocating the spirit of exploitation and enterprising, we are in pursuit of excellent and have become the specialized supplier of manufacturing, designing and developing the plastic pipe extrusion machines.

    We own the highquality staff and management supervisors and our company has entirely impelled the ISO9001:2000 quality management system.With the professional technicians and designers, we can design and produce different specification extruder production line with the feature of high capacity, low cost and the most competitive in the market according to the client’s demand.
