SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine

SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine

    • SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine
    • SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine
    • SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine
    • SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine
    • SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine
    • SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine
  • SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine

    Product Details:

    Place of Origin: Qingdao
    Brand Name: WINGS
    Certification: CE,ISO
    Model Number: SJ65

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Email negotiate
    Packaging Details: Wooden box and film
    Delivery Time: 30 workdays
    Payment Terms: T/T 30% for prepayment and 70% after machinery testing
    Supply Ability: 100 sets every year
    Contact Now
    Detailed Product Description
    Product Other Name: HDPE PE Pipe Extrusion Machine Max Production Speed: 4m-7m/min
    Plastic Materials: PP PE Granules Pipe Name: HDPE Water Or Gas Pipe
    Extruder Type: Single Screw Extruder Quality: CE, ISO
    Origin: Qingdao

    SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine

    SJ65 series 20-110mm HDPE PE Pipe Extruder With Single Screw Design is mainly composed of barrel screw,momentum driving system,heating,cooling,and electric controllers etc.

    20-110mm HDPE PE Pipe Extruder With Single Screw Design mainly used in plasticizing and extruding of PVC,PE,PP,ABS,PS,PET pipes,plates,sheets,film,profiles,granulates and other plastic products.


    20-110mm PE HDPE Pipe Single Screw Extruder Feature:

    1.PE pipe single screw extruder machine can be produced split film or flat yarn with 100% polypropylene recycled plastic granules,new material is better.

    2.PE pipe single screw extruder machine is mainly used in plasticizing and extrding of pp,pe, hdpe,ldpe pipes products.

    3.PE pipe single screw extruder makes pe pipe, range from 20 to 110mm.

    4.PE pipe single screw extruder machine is mainly used to product pe water pipe,gas pipe,drain pipe.



    General Description of 20-110mm HDPE PE Pipe Extruder With Single Screw Design :

    1.Pipe Diameter: 20-110mm

    2.Capacity: 120-200kg/h

    3.Raw Powder:PE powder

    4.Screw and Barrel:38CrMoA1A,Nitrogen Treatment

    5.Electrical Brand:SIMONS,OMRON,DELIXI,ABB,SCHNEIDER and so on,per customer requirement



    Process Flow for 20-110mm HDPE PE Pipe Extruder With Single Screw Design:

    PE granules + additive → mixing → spring feeder/vacuum feeder with hopper dryer→ single screw extruder → mould → vacuum forming machine → cooling tank machine → haul off machine

    → cutting machine → discharging stacker



    20-110mm HDPE PE Pipe Extruder With Single Screw Design Specifications:

    1. Vacuum auto Loader + Hopper Dryer 1 set
    2. Main single screw extruder 1 set
    3. SJ25/25 single screw extruder 1 set
    4. Co extrusion Mould/Die head 1 set
    5. Vacuum calibration tank 1 set
    6. Water cooling spraying tank 1 set
    7. Haul off machine 1 set
    8. Cutting machine 1 set
    9. Stacker 1 set
    11. Control System 1 set




    Q&A

    *Q: What’s the price of this machine please?

    *A: Dear customer, for each kind of our machines, we have lots of models.

    Generally speaking, we design the production lines according to different requirements of different machines from different customers. Therefore, the prices are different. So please kindly inform us your requirements. For example, the raw material, the output product size, capacity and etc. The more detailed, the better. Our Engineers will design a suitable production line for you.

    *Q: What is your advantage in this line?

    *A: Dear customer, we only focus on plastic pipe extrusion machinery manufacturing and development. That is much different with others, we live on pipe extrusion line, and pipe machinery customer is all for us.

    Company Profile:

    Qingdao Wings Plastic Technology Co., Ltd is located in Qingdao Jiaozhou City. Advocating the spirit of exploitation and enterprising, we are in pursuit of excellent and have become the specialized supplier of manufacturing, designing and developing the plastic pipe extrusion machines.

    We own the highquality staff and management supervisors and our company has entirely impelled the ISO9001:2000 quality management system.With the professional technicians and designers, we can design and produce different specification extruder production line with the feature of high capacity, low cost and the most competitive in the market according to the client’s demand.



    SJ65 20 -110mm HDPE PE Pipe Single Screw Extruder MachineSJ65 20 -110mm HDPE PE Pipe Single Screw Extruder MachineSJ65 20 -110mm HDPE PE Pipe Single Screw Extruder Machine
