China Professional PPR Pipe Extrusion Machinery Factory

China Professional PPR Pipe Extrusion Machinery Factory

    • China Professional PPR Pipe Extrusion Machinery Factory
    • China Professional PPR Pipe Extrusion Machinery Factory
    • China Professional PPR Pipe Extrusion Machinery Factory
    • China Professional PPR Pipe Extrusion Machinery Factory
    • China Professional PPR Pipe Extrusion Machinery Factory
  • China Professional PPR Pipe Extrusion Machinery Factory

    Product Details:

    Place of Origin: Qingdao
    Brand Name: WINGS
    Certification: CE,ISO
    Model Number: SJ65

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Email negotiate
    Packaging Details: Wooden box and film
    Delivery Time: 30 workdays
    Payment Terms: T/T 30% for prepayment and 70% after machinery testing
    Supply Ability: 100 sets every year
    Contact Now
    Detailed Product Description
    Product Other Name: PPR Pipe Extrusion Machine Max Production Speed: 12m/min
    Plastic Materials: PPR Granules Pipe Name: PPR Pipe
    Extruder Type: Single Screw Extruder Level: Qingdao,China

    China Professional PPR Pipe Extrusion Machinery Factory

    Key words: PPR Pipe Machine , PPR Extrusion Machine, PPR Pipe Extruder, PPR Pipe Extrusion Machine, PPR Pipe Production line, PPR Machinery Factory.



    Features of ppr pipe

    Material Random Polypropylene
    Pressure Rating 1.25 MPa, 1.6MPa, 2.0MPa, 2.5MPa
    Size: 20mm-160 mm
    Color: White, Grey or as your request
    Connection: socket fusion joint, electro fusion joint or transition joint
    Applications: Cold or hot water supply, heating system, wall heating and radiating system



    1,The main machine adopts screws specially used for ppr. Equipped with auto vacuum charger and auto constant temperature dryer hopper, it possesses features of high production, good plasticization and stable extruding.


    2,Die heads of helical type and basket type are perfect for polyolefin, and can help to produce sound melting pressure, and improve the plasticization capacity. Meanwhile, stable material-flow and pressure grade can be guaranteed.


    3, Advanced vacuum calibrating method improves the cleanliness and hardness of surface. Reasonable high-speed sprinkling cooling water tank guarantees the pipe quality and high speed stable extruding.



    4,Caterpiller of the hauling machine adopts anti abrasion alloy material, which realizes stable traction, wide frequency adjustment range and long lifespan.


    5,New generation auto dust-free cutting blade realizes smooth cutting secant, high precison and low noise.



    China PPR Pipe Extrusion Machinery Factory

    Model Diameter Extruder Line Speed Max Output Installed Power
    65/33 16-63mm 65/33 13.5m/min 120kg/h 55kw
    90/33 75-160mm 90/33 12m/min 260kg/h 120kw
    65/33 20-110mm 65/33 1-12m/min 180kg/h 150kw

    China Professional PPR Pipe Extrusion Machinery FactoryChina Professional PPR Pipe Extrusion Machinery FactoryChina Professional PPR Pipe Extrusion Machinery Factory


    Q&A

    *Q: What’s the price of this machine please?

    *A: Dear customer, for each kind of our machines, we have lots of models.

    Generally speaking, we design the production lines according to different requirements of different machines from different customers. Therefore, the prices are different. So please kindly inform us your requirements. For example, the raw material, the output product size, capacity and etc. The more detailed, the better. Our Engineers will design a suitable production line for you.

    *Q: What is your advantage in this line?

    *A: Dear customer, we only focus on plastic pipe extrusion machinery manufacturing and development. That is much different with others, we live on pipe extrusion line, and pipe machinery customer is all for us.

    Company Profile:

    Qingdao Wings Plastic Technology Co., Ltd is located in Qingdao Jiaozhou City. Advocating the spirit of exploitation and enterprising, we are in pursuit of excellent and have become the specialized supplier of manufacturing, designing and developing the plastic pipe extrusion machines.

    We own the highquality staff and management supervisors and our company has entirely impelled the ISO9001:2000 quality management system.With the professional technicians and designers, we can design and produce different specification extruder production line with the feature of high capacity, low cost and the most competitive in the market according to the client’s demand.
