Home ProductsPlastic Single Wall Corrugated Pipe Extruder Machine

Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine

Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine

    • Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine
    • Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine
    • Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine
    • Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine
    • Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine
    • Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine
  • Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine

    Product Details:

    Place of Origin: Qingdao, China
    Brand Name: WINGS
    Certification: CE,ISO
    Model Number: 16mm-50mm

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Email negotiate
    Packaging Details: Wooden box and film
    Delivery Time: 30 workdays
    Payment Terms: T/T 30% for prepayment and 70% after machinery testing
    Supply Ability: 100 sets every year
    Contact Now
    Detailed Product Description
    Plastic Processed: PE Application: Pipe
    Screw Design: Single-screw Product Other Name: Corrugated Expansion Pipe Making Machine
    Extrusion Speed: 6-10m/min Screw Type: Single Screw Extruder
    Origin: Qingdao Technology: Germany
    Quality: CE, ISO Pipe Name: Expansion Corrugated Pipe
    Machinery Color: Blue

        Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine

        The forming of the corrugated pipe joint is very perfect, no break to ensure the strength of the pipe, not easy damaged, beautiful appearance, the machine can run non-stop for a long time.

        corrugated pipe making machine

        corrugated pipe production line

        post - tension corrugated pipe making machine

        This line is used to produce different type of PP / PE single wall corrugated pipe ,the diameter of pipe can be produced

    between 9mm-160mm.The whole line can be controlled automatically ,the parameters can be set on the touch screen.

    PE / PP single wall line is made up  of some parts :feeder - dryer - extruder - mould - forming table - winder(cutter )

    Line Model

    Extruder model

    Production scope

    Output

    Total Power

    Production speed

    PE-40

    SJ-45/30

    Φ6-40mm

    60kg/h

    25KW

    6-10m/min

    PE-63

    SJ-65/30

    Φ12-63mm

    80kg/h

    30KW

    6-10m/min

    PA-40

    SJ-45/28

    Φ6-40mm

    60kg/h

    25KW

    6-10m/min

    PVC-50

    SJ50/105

    Φ16-50mm

    100kg/h

    27KW

    6-10m/min



    Plastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator MachinePlastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator MachinePlastic Corrugated Pipe Machine , HDPE PP PVC PA Corrugator Machine

    Q&A

    *Q: What’s the price of this machine please?

    *A: Dear customer, for each kind of our machines, we have lots of models.

    Generally speaking, we design the production lines according to different requirements of different machines from different customers.  Therefore, the prices are different. So please kindly inform us your requirements. For example, the raw material, the output product size, capacity and etc. The more detailed, the better. Our Engineers will design a suitable production line for you.

    *Q: What is your advantage in this line?

    *A: Dear customer, we only focus on plastic pipe extrusion machinery manufacturing and development. That is much different with others, we live on pipe extrusion line, and pipe machinery customer is all for us.

    Company Profile:

    Qingdao Wings Plastic Technology Co., Ltd is located in Qingdao Jiaozhou City. Advocating the spirit of exploitation and enterprising, we are in pursuit of excellent and have become the specialized supplier of manufacturing, designing and developing the plastic pipe extrusion machines.

    We own the highquality staff and management supervisors and our company has entirely impelled the ISO9001:2000 quality management system.With the professional technicians and designers, we can design and produce different specification extruder production line with the feature of high capacity, low cost and the most competitive in the market according to the client’s demand.
