Qingdao machinery , plastic machine for pe / pp corrugated pipe

Qingdao machinery , plastic machine for pe / pp corrugated pipe

    • Qingdao machinery , plastic machine for pe / pp corrugated pipe
    • Qingdao machinery , plastic machine for pe / pp corrugated pipe
    • Qingdao machinery , plastic machine for pe / pp corrugated pipe
    • Qingdao machinery , plastic machine for pe / pp corrugated pipe
    • Qingdao machinery , plastic machine for pe / pp corrugated pipe
    • Qingdao machinery , plastic machine for pe / pp corrugated pipe
  • Qingdao machinery , plastic machine for pe / pp corrugated pipe

    Product Details:

    Place of Origin: Qingdao, China
    Brand Name: WINGS
    Certification: CE,ISO
    Model Number: 16mm-50mm

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Email negotiate
    Packaging Details: Wooden box and film
    Delivery Time: 30 workdays
    Payment Terms: T/T 30% for prepayment and 70% after machinery testing
    Supply Ability: 100 sets every year
    Contact Now
    Detailed Product Description
    Plastic Processed: PE Application: Pipe
    Screw Design: Single-screw Product Other Name: Plastic Single Wall Corrugated Pipe Extruder
    Extrusion Speed: 10-20m/min Technology: Germany
    Quality: CE, ISO Cooling System: Water And Air Cooling
    Materials: Plastic Granules Band: YEHUA

         Qingdao machinery , plastic machine for pe / pp corrugated pipe

         The quality is stable, and can keep running at a high speed.Under the control of the water cooling and air cooling, linear velocity can reach 12-20 meters per minute, corrugated pipe forming machine can be equipped with 72 pairs of modules.

         PE / PP corrugated pipe machine

         PE / PP corrugated pipe extrusion line

         PE / PP  corrugated pipe extruder

         PE / PP corrugated pipe production line

         Plastic single wall corrugated pipe machine Process line: Raw material + master batches→mixing→vacuum feeding →material dryness →single screw extruder→extrusion mould→corrugation forming machine→meter measurer→double winder→finished product inspecting &packing

        Plastic single-wall corrugated pipes have feathers of high temperature resistance,resistant to corrosion and abrasion,high intensity,good flexibility,etc.

        They are widely used in fields of auto wire, electric thread-passing pipes, circuit of machine tool, protective pipes of lamps and lanterns wire, tubes of air conditioner and washing machine, etc.

    Extruder SJ 30/25 SJ 45/33 SJ 65/30 SJ 65/33
    Main motor power 5.5kw 11-18.5kw 30-45kw 55kw
    Molding 52pairs 45-72pairs 50-72pairs 55pairs
    Pipe diameter 4-17mm 10-35mm 40-110mm 72-200mm
    Speed 5-15m/min 15-20m/min 10-20m/min 3-15m/min
    Output 15kg/h 60-100kg/h 100-150kg/h 100-180kg/h
    Qingdao machinery , plastic machine for pe / pp corrugated pipeQingdao machinery , plastic machine for pe / pp corrugated pipeQingdao machinery , plastic machine for pe / pp corrugated pipe



    Q&A

    *Q: What’s the price of this machine please?

    *A: Dear customer, for each kind of our machines, we have lots of models.

    Generally speaking, we design the production lines according to different requirements of different machines from different customers. Therefore, the prices are different. So please kindly inform us your requirements. For example, the raw material, the output product size, capacity and etc. The more detailed, the better. Our Engineers will design a suitable production line for you.

    *Q: What is your advantage in this line?

    *A: Dear customer, we only focus on plastic pipe extrusion machinery manufacturing and development. That is much different with others, we live on pipe extrusion line, and pipe machinery customer is all for us.

    Company Profile:

    Qingdao Wings Plastic Technology Co., Ltd is located in Qingdao Jiaozhou City. Advocating the spirit of exploitation and enterprising, we are in pursuit of excellent and have become the specialized supplier of manufacturing, designing and developing the plastic pipe extrusion machines.

    We own the highquality staff and management supervisors and our company has entirely impelled the ISO9001:2000 quality management system.With the professional technicians and designers, we can design and produce different specification extruder production line with the feature of high capacity, low cost and the most competitive in the market according to the client’s demand.
