Product Details:
|
| Product Other Name: | HDPE PE Pipe Extrusion Machine | Max Production Speed: | 4m-7m/min |
|---|---|---|---|
| Plastic Materials: | PP PE Granules | Pipe Name: | HDPE Water Or Gas Pipe |
| Extruder Type: | Single Screw Extruder | Quality: | CE, ISO |
| Origin: | Qingdao |
PE plastic pipe extrusion machine / HDPE pipe production machine / PE pipe production line
It can also produce PP, PE, ABS, PPR, PEX, silicon core pipe and pipe material of other material. The planetary cutting machine is fully automatic computer digital control, it has such advantages of simple operation, reliable property, etc.
Description of PE Drainage Pipe Extrusion Line
This PE Drainage Pipe Extrusion Line can be used in PE Gas and Water Pipe which have excellent stiffness and flexibility, heat resistance, aging resistance, high mechanical strength, resistance of environmental stress cracks, resistance to creep deformation, heat-linkage, and so on.
So, this pipe production line is a preferred gas and water pipe for ductwork system between city and its suburb.
HDPE pipes start to play very important role in the city water and gas supply systems.
Flow chart of the PE pipe line:
Raw material + additive → mixing → vacuum feeding machine → hopper dryer → single screw extruder
→ color code extruder → mould and calibrator → vacuum forming machine → cooling tank
→ haul-off machine → cutting machine → discharging rack
|
model |
screw diameter |
L/D |
driving power |
output |
|
SJ-45/30 |
45 mm |
30:1 |
22/30kw |
60/80kg/h |
|
SJ-65/33 |
65 mm |
33:1 |
45/75/90kw |
150/210/250kg/h |
|
SJ-75/33 |
75 mm |
33:1 |
110/132kw |
350/450kg/h |
|
SJ-90/33 |
90 mm |
33:1 |
185/220kw |
550/700kg/h |
|
SJ-105/33 |
105 mm |
33:1 |
220/285kw |
650/800kg/h |
|
SJ-120/33 |
120 mm |
33:1 |
315kw |
950kg/h |
|
SJ-150/33 |
150 mm |
33:1 |
450kw |
1350kg/h |
Q&A
*Q: What’s the price of this machine please?
*A: Dear customer, for each kind of our machines, we have lots of models.
Generally speaking, we design the production lines according to different requirements of different machines from different customers. Therefore, the prices are different. So please kindly inform us your requirements. For example, the raw material, the output product size, capacity and etc. The more detailed, the better. Our Engineers will design a suitable production line for you.
*Q: What is your advantage in this line?
*A: Dear customer, we only focus on plastic pipe extrusion machinery manufacturing and development. That is much different with others, we live on pipe extrusion line, and pipe machinery customer is all for us.
Company Profile:
Qingdao Wings Plastic Technology Co., Ltd is located in Qingdao Jiaozhou City. Advocating the spirit of exploitation and enterprising, we are in pursuit of excellent and have become the specialized supplier of manufacturing, designing and developing the plastic pipe extrusion machines.
We own the highquality staff and management supervisors and our company has entirely impelled the ISO9001:2000 quality management system.With the professional technicians and designers, we can design and produce different specification extruder production line with the feature of high capacity, low cost and the most competitive in the market according to the client’s demand.
